CX Series Coaxial Speakers
Looking for a stage monitor engineered to satisfy professional demands for pubs, coffee shops, KTV, commercial environments and stages? Want a versatile enclosure suitable for use as a side-fill, front-fill?
Then welcome to ACM audio CX low-profile monitor housing. With ACM technology on board, these enclosures project extraordinarily rich, transparent sound, even at very high levels.
Their remarkably linear frequency response enables high volumes with reduced feedback sensitivity. It has been optimised for use as a stage monitor, its multi-functional housing shape and the integrated pole-mount cup allow it to be used for additional applications.
Technical Specifications
| CX-8 | CX-10 | CX-12 | CX-15 | |
| Freq. Range (-10dB): | 80Hz~20kHz | 70Hz~20kHz | 60Hz~20kHz | 50Hz~20kHz |
| Axial Sensitivity (1m/1W): | 94dB | 96dB | 97dB | 98dB |
| Max Calculated SPL (1m): | 118dB | 122dB | 124dB | 126dB |
| Rec. Hi pass Frequency: | 50Hz | 40Hz | 30Hz | 25Hz |
| Long Term Load Power: | 120W | 200W | 250W | 300W |
| Short Term Load Power: | 240W | 400W | 500W | 600W |
| Dispersion (HXV): | 60O x 60O | 80O x 80O | 80O x 80O | 90O x 90O |
| LF Transducer: | 8”/50mm | 10”/65mm | 12”/65mm | 15”/75mm |
| HF Transducer: | 1”/34mm | 1”/34mm | 1”/45mm | 1”/45mm |
| Crossover Frequency: | 3000Hz | 3000Hz | 2800Hz | 2100Hz |
| Nominal Impedance | 8 ohms. | 8 ohms. | 8 ohms. | 8 ohms. |
| Connectors: | Speakon NL4 x 2 | Speakon NL4 x 2 | Speakon NL4 x 2 | Speakon NL4 x 2 |
| Dim (W×H×D) | 300×338×240mm | 360×420×290mm | 400×502×345mm | 480×605×400mm |
| Net Weight: | 7Kg | 12Kg | 17Kg | 27Kg |
| Shipping Weight: | 9Kg | 14Kg | 20Kg | 30Kg |
